30
RS02
7- Q
uick programming
Procedure for facilitated gate/barrier travel programming:
N.B.:
Before you start programming, check parameter 31 (opening direction)
7.1- Procedure for facilitated gate/barrier travel programming:
APERTURA
APERTURA
Parameter 31 ON
CHIUSURA
CLOSING
Parameter 31 OFF
EN
31
33
