Vimar ELVOX SW24.W Installer Manual

22
SW24.W
EN
8 - Updating Firmware:
The control panel is equipped with a USB port that is used to update the control panel Firmware or the Wi-Fi EMC.W
communication module Firmware
Caution:
If the rmware updating procedure is not carried out properly it may damage the control panel or the Wi-Fi communica-
tion module, make sure not to interrupt the mains power supply during the update.
To perform the Firmware Update, consult the instructions provided with the Firmware
F11 Error alarm motor 2 not connected
F12 Motor 1 encoder error alarm
F13 Motor 2 encoder error alarm
F14 Microswitch undervoltage (check power supply and outputs)
F15 Safety test 1 failed
F16 Safety test 2 failed
F17 Safety test 3 failed
F18 Safety test 4 failed
F19 Motor 1 manoeuvre length/timeout alarm
F20 Motor 2 manoeuvre length/timeout alarm
F21 Motor 1 mosfet short alarm
F22 Motor 2 mosfet short alarm
F23 Blocked rotor alarm motor 1
F24 Blocked rotor alarm motor 2
F25 Overlapping leaf in closing alarm
F26 5th obstacle in closing alarm
F27 Overcurrent alarm motor 1
F28 Overcurrent alarm motor 2
F29 Radio memory full alarm
F30 Faulty radio memory alarm
F31 Short ashing alarm
F32 Gate open light short alarm
F33 No memory card alarm
F34 FW checksum alarm
F36 Board temperature alarm
