Vimar ELVOX SW24.W Installer Manual

6
SW24.W
EN
6 - Control panel programming:
6.1 - Preliminary operations
To function correctly, the control panel requires some minimum and essential settings. There are two:
- Setting the motor type.
In its default conguration, the control panel is not associated to any type of motor. The type of motor associated to
the control panel must be set.
- Gate travel calibration
The control panel must know some physical parameters of the gate in order to function correctly. The operation allow-
ing the control panel to know these physical gate parameters is called travel calibration. If this is not done, the control
panel may not perform slowdowns or detect obstacles correctly.
The instructions for these settings are given in the following paragraphs
6.2 - Using the display
The control panel is programmed using the display and the navigation buttons on board or via Smartphone/Tablet (see
paragraph "Wi-Fi connection to Smartphone/Tablet"). The control panel settings are shown on the display and can be
edited using the menu navigation buttons as shown in the following table:
Buttons Function Pressure length
OK
Switching on the display
Sub-menu entry
Conrm value change and return to menu
Instantaneous
▲
Scroll up
Increase parameter value
Instantaneous
▼
Scroll down
Reduce parameter value
Instantaneous
ESC
Exit the menu
Cancel value change and return to menu
Switching o󰀨 the display
Instantaneous
▲+▼ Resetting the card 3 s
▲+ OK Opening control 1 s
▼+ OK Closing control 1 s
ESC + OK
Display test (switches on each segment of the display and points individually in
sequence)
3 s
ESC + OK When the board is switched on the Firmware updating mode starts 3 s
PP Step-step control Instantaneous
6.3 - Menu
The control panel programming is organised into menus and sub-menus used to access and edit the parameters and
logics of the control panel. The control panel is equipped with the following rst-level menus:
All sub-menus are described in the following table
Menu Description
MOT Motor parameters setup
LRNT Travel calibration procedure run menu
TRV Travel parameter settings menu
OUT Auxiliary output conguration menu
IN Input conguration menu
LGC Operating logic settings menu
RAD Remote control management menu
STAT Diagnostic and reporting menu
EXP Expansion board management menu
LOAD Default value restore menu
PASS Protection level settings menu
