23
SW24.W
EN
9 - Control panel behaviour when loading settings:
On full uploading of the settings, some parameters are loaded, others maintained and others again are reset.
According to the type of loading, it may be necessary to calibrate the gate travel again.
To know which parameters the control panel loads, which are maintained and which are reset, refer to the table below:
Action Data Control panel behaviour
RESET
(control panel reboot)
Fixed counters
No variation
Resettable counters
Motor parameters
Gate travel data
Installer settings
Password
Remote controls
Firmware Updating
Fixed counters
No variation
Resettable counters
Motor parameters
Gate travel data
Installer settings
Password
Remote controls
LOAD MEM
(loading from memory card)
Fixed counters
No variation
Resettable counters
Motor parameters Importing data from a MEM.W memory card
Gate travel data Self-calibration on rst manoeuvre
Installer settings
Importing data from a MEM.W memory cardPassword
Remote controls
Reset/Import control panel
data from By-gate Pro app
Fixed counters
No variation
Resettable counters
Motor parameters Importing data from By-gate Pro app
Gate travel data Self-calibration on rst manoeuvre
Installer settings Importing data from By-gate Pro app
Password
No variation
Remote controls
LOAD DEF
(loading default values)
Fixed counters
No variationResettable counters
Motor parameters
Gate travel data
Travel data reset, new LRNE or LRNA calibration
required
Installer settings
Restored to DEFAULT
Password
Remote controls No variation
ERSA
(deletion of receiver
memory)
Fixed counters
No variation
Resettable counters
Motor parameters
Gate travel data
Installer settings
Password
Remote controls Complete deletion
Reset/Import receiving data
from By-gate Pro app
Fixed counters
No variation
Resettable counters
Motor parameters
Gate travel data
Installer settings
Password
Remote controls Import of remote control list from By-gate Pro app
