11
a
a
c
e
d
a
7511020
STANDARD
OPTIONAL
- Only use the emergency gate opening keys (Fig. 13/a)
when necessary.
- The platform lift may only be used by a person
stand¬ing or in a wheelchair, with or without attendant.
All other uses are forbidden.
7.9) Recovering the passenger in an emergency
Skill level required OC: Trained operator with
spe¬cic skill.
Recovery of the passenger is necessary in the event of
a lift malfunction or simply a power blackout.
WARNING: Before starting the recovery
proce¬dure, it is COMPULSORY to turn off the power
supply to the lift using the differential security breaker
installed in a box with padlock xture on the outside of
the panel (to be installed by the customer).
This ensures that the lift cannot be moved accidentally.
Ensure that the gate at the oor is locked.
- Remove the cap that accesses the brake block lever
(Fig. 12/c).
- Remove the cap from the casing to access the hand-
operation mechanism (Fig. 12/a).
- Insert the handwheel provided into the hole in the
casing and t it on the square drive pin.
- In case of side operation by hand (option), insert the
special crank handle (Fig. 12/d) into the hole and t it
to the pin (Fig. 12/e).
- Turn the hand wheel or crank handle to move the
platform to the oor. If the lift is lowered, turning the
handwheel or crank handle requires less effort.
- At the destination oor, remove the handwheel or crank
handle and replace the cap.
- Open the lift gate manually
- To open the gates at the oor by hand, use the trian-
gular key (Fig. 13/a).
FIG.12
FIG.13
7512020
