8
7511020
5. TECHNICAL DATA
- Lifting system
Worm screw plus motor
- Operating data
Travel direction Up/Down
Speed 0.05 m/s - 0.1 m/s
Payload See nameplate on unit
- Duty cycles
Normal duty 20 Cycles/day
- Ambient conditions from -5° to +60° C. Humidity 90% max. (use in
Temperature bathrooms and swimming-pools is
not permit¬ted).
- Electrical system
Motor 2.2 kW
Voltage 230 V (50 Hz) Three-phase / Single-phase
Auxiliary circuit at 24 VDC
IP protection degree IP 54
- Controls Hold-to-run type; on the lift: protected up and
down buttons, illuminated call buttons at oors.
All buttons are of hold-to-run type; the controls
at the oors are enabled by means of removable
keys.
4) INTENDED AND IMPROPER USES
4.1) Intended Uses
The S11 platform lift is a lift system designed for one disabled person, standing or in a wheelchair +
attendant (if any), who must be trained in the lift’s operation.
When using the lift, compliance with the instructions provided on the signs tted to it is compulsory.
4.2) Improper Uses
The user must follow the instructions provided in this manual.
The following are forbidden when using the S11 platform lift:
- Lifting anything not specied in point 4.1
- Exceeding the rated load stated on the nameplate.
- Operation by a user not trained in the use of the lift.
- Failure to follow the instructions provided on nameplates tted to the lift.
- Performance of maintenance work by anyone without the skills needed for the various procedures.
WARNING: NO MODIFICATIONS ARE PERMITTED, FOR ANY PURPOSE.
7512020
