17
7511020
10) ELECTRICAL WIRING DIAGRAMS
The electrical wiring diagrams are in the folder supplied
with the lift.
11) VIBRATION – AIRBORNE NOISE LEVELS
a) Vibration
The lift causes vibration in the passenger’s body with
the following characteristics:
- low frequency, very low acceleration;
- short exposure cycles for the transported person.
This parameter is therefore insignicant for safety
purposes.
b) Airborne noise: less than 70 dBA
12) GUIDANCE ON DISPOSING OF LIFT PARTS
AND SUBSTANCES
a) Disposing of rubber, plastics and packaging
material.
Place in clean containers and consign to disposal
cen¬tres authorised under the relevant regulations.
Possible remedies
The platform does not move in either direction Emergency STOP pressed Turn the button
clockwise through 45°
Overload cut-out tripped Press the reset button
Differential circuit-breaker Call a VIMEC authorised
tripped technician
Lift gate Close the gate properly.
Gates and locks Close the gates properly
Safety gear switch Replace drive bushing
The platform does not respond to the “down” Obstacles underneath the Remove the obstacles
command platform
The platform does not respond to the “oor call” Gates and locks Close the gates properly
command
The platform does not respond to the “up” Platform guard board failing to rise
command
9.3) Troubleshooting
Skill level required: O - trained operatorProblem Possible causes
7512020
