Safety - read this first
Warning Symbols in this Operators Guide
Where there is a risk of personal injury, injury to others, or damage to the ped-
estal or associated equipment, comments appear, highlighted by the word
WARNING! and supported by the warning triangle symbol.
Warning symbols on the pedestal
On encountering the warning triangle and open book symbols it is imperative
that you consult this operators guide before using this pedestal or attempting
any adjustment or repair.
Critical data
Mass
Column 19 kg (41.8 lb)
Trim weights (6 off) total 3.4 kg (7.5 lb)
Skid 9.4 kg (20.7 lb)
Load
Maximum load 55 kg (120 lb)
Pressure
Maximum pressure 9.65 bar (140 psi)
≤9.65 bar
19
kg
<55 kg
9.4
kg
