Technical data
Studio OB
Payload 55 kg (120 lb) 55 kg (120 lb)
Column weight 19 kg (41.8 lb) 19 kg (41.8 lb)
Skid weight 9.4 kg (20.7 lb) 9 kg (19.8 lb)
Trim weights (6 off - total) 3.4 kg (7.5 lb) 3.4 kg (7.5 lb)
Total pedestal weight 31.8 kg (70 lb) 31.4 kg (69.1 lb)
Minimum height 66.6 cm (26.2 in.) 68.5 cm (27 in.)
Maximum height 147.5 cm (58.1 in.) 150 cm (59.1 in.)
On-shot stroke 41 cm (16.1 in.) 41 cm (16.1 in.)
Skid leg radius 48 cm (19 in.) 48 cm (19 in.)
Doorway tracking width 97 cm (38 in.) 97 cm (38 in.)
Transit doorway width 86 cm (34 in.) 86 cm (34 in.)
Narrow doorway width 70 cm (27.5 in.) 70 cm (27.5 in.)
Wheel diameter 12.5 cm (5 in.) 15 cm (6 in.)
Steering ring diameter 53.4 cm (21 in.) 53.4 cm (21 in.)
Max working pressure 9.65 bar (140 psi) 9.65 bar (140 psi)
Relief valve pressure 11.38 bar (165 psi) 11.38 bar (165 psi)
Usage
The Pro-Ped Pedestal is designed for use in television studios and on location to support and bal-
ance a pan and tilt head, camera and ancillary equipment weighing up to 55 kg (120 lb).
The Pro-Ped Pedestal is intended for use by television camera operators.
Further information
For further information or advice regarding this pedestal, please contact Vinten Broadcast Limited,
your local Vinten distributor or visit our website.
For full details on maintenance and spare parts, please refer to the Pro-Ped pedestal Maintenance
Manual and Illustrated Parts List - Publication Part No. 3983-9, obtainable from Vinten Broadcast
Limited or your local Vinten distributor. For information on-line, visit our website at
www.vinten.com.
WARNING! If you do not understand how to operate this pedestal, do not
attempt to use it.
Maintenance beyond that detailed in this Operators Guide must
be performed only by competent personnel in accordance with
the procedures laid down in the Maintenance Manual.
