Skid clamp adjustment
To adjust the skid clamp:
The skid clamp (14) is applied or released by turning the handle clockwise or counter-clock-
wise. The handle has a pull-off/push-on ratchet adjustment. To take up wear, pull the han-
dle away from the spindle, rotate counter-clockwise and release.
Repeat the above procedure, as necessary, until the clamp locks when applied but allows
free movement when released.
Skid Clamp Adjustment
(14)
