Introduction
The Pro-Ped pedestal comprises a central two-stage telescopic column and a skid assembly with
castoring wheels. For transport and storage, the column and skid may be separated and the skid
folded.
The top stage (4) may be pressurized manually, using the self-contained pump, or from an exter-
nal pressure source. Balance is achieved with approximately 1.5 bar pressure for every 10 kg of
load (10 psi for every 10 lb). Trim weights (8) are provided for fine balance.
The skid comprises a centre casting with carrying handle, a fixed leg and two folding legs. Each
leg carries a braked castoring wheel (15) and a foot support with strap (16) to secure the column
leg. Two versions of the skid are available. The OB skid has 150 mm (6 in.) wheels. The studio
skid has 125 mm (5 in.) wheels with cable guards (11) and track locks (12) which provide castor,
track or steer movement of the pedestal.
