Pro-Ped Pedestal (Studio Version)
(1) Four-bolt mounting plate
(2) Control valve
(3) Pressure gauge
(4) Top stage
(5) Drag control
(6) Bottom stage
(7) Safety catch
(8) Trim weight
(9) Long strut
(10) Velcro strap
(11) Cable guard
(12) Track lock pin
(13) Short strut
(14) Skid clamp
(15) Wheel brake
(16) Foot support and strap
(17) Trim weight stowage
(18) Outer tube
(19) Bottom clamp
(20) Top clamp
(21) Steering ring
(22) Weight tray
(23) Schrader valve and cap
