Repositioning the wedge adaptor
The wedge adaptor (1) is secured by four cap head screws (3) which pass through the wedge
adaptor into the slide plate (14).
Fig 8 Platform slide clamp adjustment
Fig 9 Wedge adaptor
(12.1)
(12.3)
(12.2)
(12)
(1)
(14)
(3)
