Safety - read this first
English—Original Instructions
The original instructions presented in this operators guide were written in English, and subse-
quently translated into other languages. If you are unable to understand any of the translated lan-
guages, contact Vinten or your distributor to obtain a translation of the original instructions (EU
Countries).
Warning Symbols in this Operators Guide
Where there is a risk of personal injury, injury to others, or damage to the pan
and tilt head or associated equipment, comments appear, highlighted by the
word WARNING! and supported by the warning triangle symbol.
Technical data
Weight 15 kg (33 lb)
Height to wedge adaptor mounting face 24.8 cm (11.3 in.)
Length 22.5 cm (8.9 in.)
Width 34.2 cm (13.5 in.)
Typical payload 10-90 kg (22-198 lb) - See balance graph (Fig 3)
Tilt range 45 kg payload to ±90°, 90kg payload to ±60°
Pan range 360°
Pedestal/tripod fixing Four-hole flat base
`Quickfix' adaptor
Mitchell adaptor
Further information
For further information or advice regarding this pan and tilt head, please contact Vinten Broadcast
Limited, your local Vinten distributor (see back cover) or visit our website.
For details on maintenance and spare parts, please refer to the Vector 90 Pan and Tilt Head Main-
tenance Manual and Illustrated Parts List (Publication Part No. V3998-4990) This is obtainable
from Vinten Broadcast Limited or your local Vinten distributor. For information on-line, visit our
website at
www.vinten.com.
