Chapter 3. Components and Installation of SYLFIRM X
3.1 Main Device Components
No.
Name
Description
1 ON/OFF Switch For turning the power on and off
2 Display LCD A display that shows current operational settings
3 Operation Touch Screen For configuring operational settings or functions
4 Power LED Led for check the power
5 Jog Dial
A dial that changes functional values or equip mode for consumable
tip.
6 Hand-piece Holder A part that holds the Hand-piece in place
7 Hand-piece Connector
Connector between the Hand-piece and the main device
8 Foot switch Connecter
Connector between the foot switch and the main device
9 Power Inlet For turning the main power on and off
10 Back Cover
A cover that can be removed when repairing or replacing
components of the main device
