Blue: Turned on/Working normally/Fully charged/Wi-Fi Connected
Breathing yellow: Charging
Blinking red: Error
Installation
1. Connect the charging dock to the power outlet.
3. Place the charging dock on a level ground against a wall.
2. Install the side brush on the upper-le corner of the vacuum-mop, as
shown in the figure. An extra side brush in the package is provided as a
spare and does not need to be installed.
4. When using the vacuum-mop for the first time, press and hold the
buon for 3 seconds to turn on the vacuum-mop. Once the
indicator lights up, manually place the vacuum-mop onto the
charging dock to charge. Then just press the buon when the
vacuum-mop is cleaning, it will automatically go to the charging
dock to recharge.
05
0.
5 m
e
t
e
rs
0.
5
m
et
e
rs
1.
5
m
e
t
e
r
s

Other manuals for VIOMI V3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the VIOMI V3 and is the answer not in the manual?

VIOMI V3 Specifications

General IconGeneral
Suction Power2600 Pa
Battery Capacity4900 mAh
Dustbin Capacity550 ml
Water Tank Capacity550 ml
NavigationLDS Laser Navigation
Runtime150 minutes
MappingYes, Multi-floor Mapping
Mopping FunctionYes
Climbing Ability20 mm
Charging Time4 hours
Weight3.6 kg
ConnectivityWi-Fi
Cleaning ModesAuto, Spot, Edge
ControlMobile App, Voice Control (Amazon Alexa, Google Assistant)
Virtual WallsYes
