Viotek GFI34CB - Product Overview; Monitor Buttons; Monitor Ports

6
Section 3: Product Overview
3.1 – Monitor Buttons
6
Audio Output: Insert one end of the audio cable into an external audio
source, e.g., speakers or headphones, to pass audio signals through the
monitor.
7
HDMI 1.4 Connectors: Insert one end of the HDMI cable into the
computer’s HDMI output and connect the other end to the monitor’s HDMI port.
8
DisplayPort (DP) 1.2 Connector: Insert one end of the DP cable into the
computer’s DP output and connect the other end to the monitor’s DP port.
9
DC IN Power Connector: Insert the power cable to supply power to the monitor.
8 6 9 7
2
3
4
5
1
1
M Menu Button
: Press to display the OSD menu or enter sub-menus.
2
Up Button
: Press to move up in the menus.
3
Down Button
: Press to move down in the menus.
4
E Exit Button
: Press to exit.
5
Power Button
: Press to turn the monitor on/off.
3.2 – Monitor Ports
HDMI 2HDMI 1
