Section 4: Stand Installation
1. Open the package and take out the product with foam still attached. Gently place
it on a desktop or table.
2. Take out the stand and base. Connect the stand into the base hole and use the
included screwdriver and four NO.1 screws to fasten base to the stand.
Base
Stand
Hole
NO. 1 Screws x 4
3. Attach the stand to monitor via the opening on the back and use one NO.2 screw
to x the stand onto the monitor. Make sure the stand is securely attached to the
back of the monitor. Remove face-down the monitor from the remaining foam
section and stand it up on the desired surface.
NO. 2 Screw x 1
Decorative Cover
If needed, the stand can easily be detached from the monitor by loosen the NO.
2 screw on the top of stand. Gently place monitor face-down on a at surface,
then unscrew the stand to remove it.
