Section 5: Wall Mounting
VESA and/or mounting accessories not included.
1. Open the package, take out the monitor with the foam still attached, and gently
place it on a desktop or table. If the monitor is attached to the stand, remove the
stand by pressing the button on the back of the monitor just above the stand.
2. At the back of the monitor, attach the four NO. 2 screws onto the mounting holes
on back of monitor.
26mm NO. 2 Screws x 2
10mm NO. 2 Screws x 2
3. Follow the directions that came with your mounting kit (not included) to mount
the monitor on the wall or monitor stand.
Wall
Mounting Base
(Not included)
To Next Page
