7
Section 4: Stand Installation
Keep the foam underneath the monitor before attaching the stand.
1. Open the package, take out the product with foam still attached, and gently place
it on a desktop or table.
2. Take out the two parts of the stand, and remove the foam covering the back of the
monitor. And take out the decorative cover from the package.
3. Insert the stand stem into the opening on the back of monitor then use the
included screwdriver and four PM4 screws to fasten it to the monitor. Install the
decorative cover back on opening on the back of monitor.
Stand Stem
PM4 Screws
10mm x 4
Decorative Cover
4. Use the BM5 x10mm screw to fasten the base to the stem.
BM5 Screw
10mm x 1
Base
5. Make sure the stand is securely attached to the back of the monitor then remove
the monitor from the remaining foam and stand it up on a table or desk.
To Next Page
