Viotek GNV27DB2 - Section 12: Specifications

16
Section 12: Specifications
Item Detail
Model Number GNV27DB2
Screen Size 27’’
Curvature 1500R
Viewing Angle approx. 178° (H); 178° (V)
Aspect Ratio 16:9
Resolution 2560 x 1440p
Backlight E-LED
LED Indicator Power on: Blue (solid); Power saving: Blue (ashing)
Typical Brightness 300 cd/m
2
(TYP); 320cd/m
2
(MAX)
Default Color Temp. 6500
Color Gamut 98% sRGB; 85% NTSC
Contrast Ratio 3000:1 (Static)
Pixel Pitch 77.7 x 233.1 um
Response Time 6ms (OD)
Refresh Rate 144Hz
Ports
1x DP, 1x HDMI 2.0, 2x HDMI 1.4, 3.5mm audio out (3.5
mm)
Power DC 12V, Min 4A
Power Consumption Typical: 36W, Max: 42W; Standby <=0.5W
OSD Language
English, Español, Русский, Français, 한국, 日本語, 简体
中文
Usage Temp.
32°F~104°F (operating), -4°F~140°F (storage), 10-85%
RH (non-condensing)
Tilt Angle
Forward 5°+ 2°; Backward 15°+ 2°
VESA Mounting 75 x 75 mm
Dimension (With Stand) 24.26 x 17.84 x 7.7 in (616.2 x 453.1 x 195.7 mm)
Weight 10.69 Ib. / 14.82 Ib. (incl. packaging)
