Viotek NBV24CB2 User Manual

10
7.1 – OSD Menu Functions
Main Menu Sub-Menu Options Description
Luminance
Brightness 0~100 Adjust display brightness
Contrast 0~100 Adjust display contrast
ECO
Standard, EYES,
Game, RTS,
FPS, Movie
Set visual mode
DCR
On Turn on DCR function
Off Turn off DCR function
Image Setup Image Ratio Wide, 4:3 Set aspect ratio
Color Setup
Color temp.
Warm, User,
Cool, Normal
Set the display color temp. based
on your preference
Red 0~50
Customize RGB componentsGreen 0~50
Blue 0~50
OSD Setup
Language English Set OSD language
H. Position 0-100
Adjust the OSD horizontal
position
V. Position 0-100 Adjust the OSD vertical position
Time out 0~60
Set how long the OSD remains
open after non-use
Transparency 0-100 Set the OSD overall transparency
Reset
Auto Cong. N/A
Auto congure the monitor
settings
Auto Color N/A Auto set the color of monitor
Reset N/A Reset monitor congurations
Extra
Input Select HDMI, VGA Display the input signal
Mute On, Off Turn mute function on/off
Volume 0-100 Adjust audio volume
Free Sync On, Off Turn on or off Free Sync function

Viotek NBV24CB2 Specifications

General

Screen Type	led
Wall Mount	75mm x 75mm
OS Compatibility	mac, windows
Color	black
Tiltable	yes
Webcam	no
Screen Size	24 inches
Panel Type	va
Aspect Ratio	16:9
Resolution	1920 x 1080
Native Resolution	1920 x 1080
Refresh Rate	75hz
Horizontal Viewing Angle	178 degrees
Vertical Viewing Angle	178 degrees
Response Time	8 milliseconds
Brightness	250 candela per square meter
Contrast Ratio	1, 000, 000:1
Synchronization	freesync (amd adaptive sync)
HDR	no
VGA Ports	1
Interface Connectors	1 x vga
HDMI Ports	1
Power Saving Mode	0.5 watts
Power Consumption	29 watts
Width with Stand	21.2 inches
Depth without Stand	8.2 inches
Height without Stand	16.3 inches
Net Weight without Stand	6.6 pounds
Built-In Speakers	no
