7
Section 4: Stand Installation
Keep the foam underneath the monitor before attaching the stand.
1. Open the package and take out the monitor with foam still attached. Gently place
it top-down on a desktop or table.
2. Take out the stem and base. Use a screwdriver (not included) and the included
one screw to fasten base to the stem.
Screw x 1
Stand Stem
Base
3. With the stand fully assembled, attach it onto the back of monitor.
4. Remove the remaining foam on monitor and stand it up on a at, level desktop or
table. Press the button to remove the monitor from the bracket if mounting.
Button
Make sure the monitor is laid on a at surface before removing the stand.
