Chapter 4 Analog Input Manual VIPA System SLIO
4-6 HB300E - SM - Rev. 09/38
... continue RTD
Measuring range (function number) Measuring value Signal range Range
--- ---
overrange
0 ... 60Ω
0 ... 32767
nominal range
3 wire: 0 ... 60Ω
(78h)
--- ---
underrange
--- ---
overrange
0 ... 600Ω
0 ... 32767
nominal range
3 wire: 0 ... 600Ω
(79h)
--- ---
underrange
--- ---
overrange
0 ... 3000Ω
0 ... 32767
nominal range
3 wire: 0 ... 3000Ω
(7Ah)
--- ---
underrange
--- ---
overrange
0 ... 60Ω
0 ... 32767
nominal range
4 wire: 0 ... 60Ω
(80h)
--- ---
underrange
--- ---
overrange
0 ... 600Ω
0 ... 32767
nominal range
4 wire: 0 ... 600Ω
(81h)
--- ---
underrange
--- ---
overrange
0 ... 3000Ω
0 ... 32767
nominal range
4 wire: 0 ... 3000Ω
(82h)
--- ---
underrange
--- ---
overrange
0 ... 60Ω
0 ... 6000
nominal range
2 wire: 0 ... 60Ω
(90h)
--- ---
underrange
--- ---
overrange
0 ... 600Ω
0 ... 6000
nominal range
2 wire: 0 ... 600Ω
(91h)
--- ---
underrange
--- ---
overrange
0 ... 3000Ω
0 ... 30000
nominal range
2 wire : 0 ... 3000Ω
(92h)
--- ---
underrange
--- ---
overrange
0 ... 60Ω
0 ... 6000
nominal range
3 wire: 0 ... 60Ω
(98h)
--- ---
underrange
--- ---
overrange
0 ... 600Ω
0 ... 6000
nominal range
3 wire: 0 ... 600Ω
(99h)
--- ---
underrange
--- ---
overrange
0 ... 3000Ω
0 ... 30000
nominal range
3 wire: 0 ... 3000Ω
(9Ah)
--- ---
underrange
--- ---
overrange
0 ... 60Ω
0 ... 6000
nominal range
4 wire: 0 ... 60Ω
(A0h)
--- ---
underrange
--- ---
overrange
0 ... 600Ω
0 ... 6000
nominal range
4 wire: 0 ... 600Ω
(A1h)
--- ---
underrange
--- ---
overrange
0 ... 3000Ω
0 ... 30000
nominal range
4 wire: 0 ... 3000Ω
(A2h)
--- ---
underrange
continued ...
