Chapter 4 Analog Input Manual VIPA System SLIO
4-20 HB300E - SM - Rev. 09/38
Data VIPA 031-1BD30
Number of inputs 4
Power supply DC 24V via power module
Input range 0 ... 10V
Current consumption
5V
24V
70mA
15mA
Internal resistor 100kΩ
Limit frequency input filter 1kHz
Resolution 12bit
Conversion time 4ms all channels
Measuring error ±0.2%
(relating to operational limit at 25°C)
Isolation 500Veff (field voltage to the bus)
Module ID 0404 15C4
Bit-width in the process image Input: 4x16bit data
Configurable yes
Technical data
