4
wire connection guide
immobiliser harness wiring diagram
___
___
___
___
___
___
power harness wiring diagram
___
___
___
NNOOTTEE::
Please remove all wire description tags from wiring after
connection to the vehicle.
GND2 (Ground 2)
GND1 (Ground 1)
+12V
1
2
3
NNOOTTEE::
All wires are BLACK. Each wire is marked with its function.
The description listed below is the marking on each wire and then
its function, in brackets.
IGN: Ignition Side (Ignition Interrupt Com)
STR: Key Side (Starter Interrupt 87)
Fuel Pump Input (Fuel Pump Interrupt 87)
IGN: Key Side (Ignition Interrupt 87)
STR: Starter Side (Starter Interrupt Com)
Fuel Pump Output (Fuel Pump Interrupt Com)
1
2
3
4
5
6
NNOOTTEE::
All wires are BLACK. Each pair is an immobiliser circuit
input and output. Each wire is marked with its function. The descrip-
tion listed below is the marking on each wire and then its function,
in brackets.
