Transmitter Configurations
The transmitters can be programmed with the standard or three-button
configurations by using the Auto Learn functions in the Transmitter/Receiver
Learn Routine.
Standard Configuration
When programmed for standard configuration, the transmitter buttons are
assigned to the following functions:
operates Arm only
operates Disarm only
operates Channel 2 and Silent Mode
operates Panic
and
operate Channel 3
Three-button configuration - Optional not included
operates Arm/Disarm
operates Channel 2 and Silent Mode
operates Panic
and
operate Channel 3
NOTE: Multi Level Security Arming feature is not available with the three-
button.
