The status LED flashes to report the last shutdown for one minute or until the ignition is turned ON, as shown
in the following table:
Status LED Flashes Shutdown Mode
1 flash Runtime expired
2 flashes Over-rev shutdown
3 flashes Low or no RPM
4 flashes Transmitter shutdown (or optional push button)
5 flashes (+) Brake shutdown
6 flashes (-) Hood shutdown
7 flashes Timer mode/Turbo mode/Manual mode error*
8 flashes Neutral safety shutdown
9 flashes Low battery (voltage mode)
11 flashes Wait-to-start input timed out
* Timer Mode error: Ignition is ON or shutdown input is active when activating Timer Mode.
Turbo Mode error: Turbo Mode is programmed OFF, engine is not ON or shutdown input is active.
Manual mode error: MTS mode not enabled.
Startup Diagnostics: If the vehicle fails to activate the remote start, the remote start module will notify you
via 2-way remote control and will flash the parking lights on the vehicle to notify you of what caused the no-
start situation.
Parking Light Flashes:
5 flashes Brake wire is active
6 flashes Hood pin wire is active
7 flashes Manual transmission mode is enabled and not initialized
8 flashes Neutral safety wire has no ground or the neutral safety switch is OFF
Programming System Features
The System Features Learn Routine dictates how the unit operates. It is possible to access and change most of
the feature settings using the Control Center button.
1. Turn the ignition ON, then OFF.
2. Select a Menu. Press and hold the Control Center button. The number of LED flashes and horn honks
indicates the Menu number. 1 LED flash and honk indicates Menu 1, 2 LED flashes and honks - Menu 2
and 3 LED flashes and honks for Menu 3.
3. When the desired Menu LED flashes and honks are observed, release the Control Center button.
4. Select a Feature. Press and release the Control Center button the number of times corresponding
to the feature desired to change. Then press and hold one more time to select the features. Do not
release the Control Center button.
5. Program the Feature. While holding the Control Center button, you can program the feature using the
remote control.
The Control Center LED will flash and the horn will honk the number of times equal to the option chosen.
For features with only two options;
= option 1, while = option 2.
For features with more than two options;
selects the options in ascending order, while selects them in
descending order.
Note: Pressing button resets the feature to the factory default.
