Viper 5002 - L L C C D D S S C C R R E E E E N

2
© 2006 directed electronics
LLCCDD ssccrreeeenn
1. Transmit 13. Battery level indicator
2. Out of range 14. Remote start (option)
3. Receive 15. Field disturbance sensor *
4. Auxiliaries 16. Shock sensor setting
5. Garage door (519H2 option) 17. Vibrator
6. Warn Away
®
18. Ignition
7. Alarm 19. Hood
8. Ultrasonic sensor * 20. Vehicle number
9. Tilt sensor * 21. Door
10. Trunk 22. Arm
11. Glass breakage sensor * 23. Disarm
12. Shock sensor
* Optional sensors. Additional parts and labor required
