37
© 2006 directed electronics
system status chirps
The siren will chirp when arming/disarming the system. The
pattern of chirps will audibly report the system’s status as
described below.
table of zones
A zone is represented by the number of LED flashes used by the
system to identify a particular type of input. Standard input
assignments are listed in the following table, along with spaces to
write in any optional sensors or switches that have been installed.
ZONE
(Number of DEALER-INSTALLED
LED Flashes) DESCRIPTION OPTIONS
1 Instant trigger - hood pinswitch
2 Instant trigger - a heavier impact
detected by the shock sensor
3 Door switch trigger
4 Instant trigger - for optional
➜
Action Number of Chirps Description
Arm 1 System armed
Arm 1 (3-second delay), 1 System armed with
Bypass Notification
Disarm 2 System disarmed
Disarm 4 System disarmed with
Tamper Alert
Disarm 5 System disarmed NPC
active
➜
