Virax VISIOVAL VX - 4 Technical Data; Screen; Fixed Camera Head 26 MM Ø (VX-26)

46
4. Technical data
4.1. Screen
Fig. 1: Screen
4.2. Fixed camera head 26 mm Ø (VX-26)
Miniature camera head
Designation
Specification
TFT screen
7“ / 16:9 and 4:3 (Presetting 16:9)
800 x 480 pixels
Weight
400 g
Housing dimensions
176 x 114 x 32 mm
Video output
FBAS signal
Power supply
Via camera system
Voltage
12 V
Operating temperature
0 to 40 °C
Storage temperature:
- 20° to 50°C
Camera system connection cable
2 m
Designation
Specification
Type
Colour CMOS 1/3“ - 768 x 576 pixels
Lens
f = 2.3 mm, F = 2.5
Image capture angle
130°
Light sources
White LEDs
Protection
Watertight as per IP 68 (30 Min, 30 m)
Dimensions
26 mm x 38 mm
Built-in transmitter frequency
9.2 kHz
