5. Construction and operation
5.1. Video inspection system
Explanation of the parts
15. Screen
16. Screen command key
17. Camera keys and controls with the recording and Play Fonction Home functions (with 40
mm Ø head) to adjust the camera head into the straight position, menu to adjust video
quality.
18. Watertight camera head:
Visioval
®
VX-40 / VX-Switch: 40 mm Ø colour, swivelling and turning camera head
Visioval
®
VX-26: 26 mm Ø colour camera head
19. System switch for the following functions
- On / Off (System)
- Meter counting reset
- Esc
- Clear (in SHIFT mode)
20. Memory card slot
21. Mini USB connection
22. Power supply connection
23. Video output
24. Accessory storage area
25. Spare battery
26. Power supply adapter
27. Active battery
28. Accessory storage area 2
