Operator’s Manual
Operating Procedure
9/50
Figure.1.4-01 ‘Front View (Door Closed)’
Figure 1.4-02 ‘Front View (Lids Open)’
Legend:
1
Sample Rotor
Wash Buffer Container
2
Sample Needle Arm
7
Distilled Water tank
3
Strip Rotor
8
Additional Reagents Rack
4
Sample Needle Washing Well
9
Cover Locking Magnets
5
Strips Waste Box
Waste liquid container
