Operation & setup
www.visioneng.com/support
11
Getting the most from your system
Routine maintenance
The outside of the instrument should be wiped down
with a damp cloth to remove dirt and dust.
The instrument and accessories should be checked for
loose or damaged components.
When not in use, protect your system with the dust
cover.
Always disassemble the system prior to moving.
Environmental considerations
This equipment is designed for indoor use in the
following conditions:
Up to 2000m altitude
Between 5° and 40°C ambient temperature (10° to
35° recommended limits)
Power supply; 100-120V/ 220-240V, 50/60Hz with
voltage uctuations up to 10% of the nominal voltage
Transient over voltages typically present on the Mains
supply
Maximum relative humidity of 80% for temperatures up
to 31°C decreasing linearly to 50% relative humidity at
40°C.
This system is an accurate, industrial gauging instrument.
To achieve the optimum accuracy and repeatability, the
following considerations should be taken into account:
Position the system on a rm, rigid and level table.
Avoid locating the instrument near to a source of
vibration.
Do not place the instrument close to a radiator or
similar heat source.
Do not place the instrument close to a cold temperature
source such as an air conditioning unit.
Do not position the instrument in direct sunlight, or
where bright reections will affect the image.
The equipment should be positioned so that access
to the mains input connector is always available
If the system you purchased is a Video
product and you purchased your own PC,
Vision Engineering recommend the use of a
powered USB hub for the camera signal.
