22
Version 1.1.0
Release Date : Feb. 24, 2011
9. Dimension(mm)
10. Specification
MODEL Full HD CCTV Box Camera
Sensor Device Sony 1/2.8 inch progressive scan CMOS, 3MegaPixel
Total Pixels
2144(H) x 1588(V) 3.4 Megapixel
Effective Pixels
2096(H) x 1561(V) 3.27 Megapixel
Scanning System Progressive Scan
Horizontal
More than 1100 TVL
S/N Ratio More than 52dB
Min. Illumination
1.0 Lux with DSSX2 (F1.2, 30IRE, AGC On),
Shutter Speed
1/30s Default,(Long Exposure Mode, ~1Sec)
Video Output
1920 x 1080P 60/50/30/25/59.94/29.97, 1920x 1080i 60/50/59.94/
1280x 720P 60/50/30/25//59.94/29.97 (Mode Select)
Video Output Format
2.97G/s, 3G-SDI Output (SMPTE 424M)
AV Output 1V p-p Composite. 75 Ohms
Digital Output SDI Output
Day & Night D/N Output Port, ICR
Serial Port RS485
Lens C/CS Mount Lens
