5. Loosen all 6 Screws until you feel the
Porter Cable Router Assembly has
detached from the Router Rail Plate.
6. Then remove all 6 Screws (3 on the Right
and 3 on the Left) and detach the Porter
Cable Router Assembly from the Router Rail
Plate.
Porter Cable Router Assembly
Router Bracket
Plate
Router Rail Plate
Remove these 3 Screws on the
Right (then 3 on the Left Side)
To Next Page
