High Frequency Router
Assembly
Router Vacuum Head
Router Vacuum Hose
Connector
Vacuum Hose Hanger
Router Bracket
Plate
Router Housing
1. Make sure that the High Frequency
Router Assembly and the electrical power is
disconnected before you begin any
disassembly.
2. Then unplug the Connector from behind
the Router Housing and rest the cable on
the Vacuum Hose Hanger.
3. Disconnect the plastic Vacuum Hose Pipe
from the Router Vacuum Head and place it
safely away from the Router.
(Continued on Pg. 18)
Router Rail Plate
To Next Page
