Vision Marathon + User Manual

26
MODEL
8K
10K
SINGLE PHASE
3-PHASE
PROTECTION
Overload
AC Mode:
1) <120% delay 15 minutes before switching to bypass.
2) 120%~150% delay 30 seconds before switching to bypass.
3) >150% 10 ms. before switch to bypass
Backup Mode:
1) <120% delay 30 seconds before shut down.
2) 120%~150% delay 10 seconds before shut down.
3) >150% delay 10 ms. before shut down.
Short Circuit
Inv. Mode: Halt whole system and no output
Bypass Mode: Break Input fuse or Trip AC Breaker
Overheat
AC Normal: Switch to bypass
AC Abnormal: Alarm buzzer beeps continuously, Fault LED lights up then
Completely shutdown the UPS
High Voltage Trip-Off
Switch to Battery Mode
Battery Low
Alarm continuously till battery cutoff
Noise Suppression
Complies with EN50091-2
Spike Suppression
Complies with EN61000-4-5
ALARM
Audible and Visual
Line Failure, Battery Low, Transfer to Bypass, System Fault Conditions
PHYSICAL
Dimensions
(WxHxD, mm)
400x842x730
400x1112x730
Net Weight (Kgs)
160 kgs
183kgs
253 kgs
Outlets (IEC/Local)
Terminal Block
ENVIRONMENT
Temperature
0℃~40℃
Humidity
30~90% RH Maximum, Non-Condensing
Acoustic
<60 dB (at 1 meter)
COMPUTER INTERFACE
Interface Type
Standard RS232 Interface (Megatec protocol)
SNMP Adaptability
Yes, Plug & Play Slot for Standard SNMP Card Available
Relay Contact
Interface
Yes, Plug & Play Slot
Operating Systems
Compatibility
Novell Netware, Windows, OS/2, NetLite, MS-DOS, HP-UX, AIX, SUN
OS, UNIX, XENIX, Linux, etc.
SAFETY CONFORMANCE
Safety Standard
EN50091-1,
EMC Standard
EN50091-2, EN61000-3-3, EN61000-3-2
Marks
CE
Above specifications are subject to change without prior notice. Trademarks of MegaTec, RUPS, IBM,
MS-DOS, Novell Netware, Windows, OS/2, NetLite, HP-UX, AIX, SUN, UNIX, XENIX, and Linux are
registered trademarks of their respective companies.

Vision Marathon + Specifications

General

Topology	Line Interactive
Frequency	50/60Hz
Battery Type	Sealed Lead-Acid (SLA)
Communication Interface	USB
Operating Temperature	0°C to 40°C
