INTRODUCTION
BACK
RecordLED
BLUELED
CommunicationLED
GreenLED
PANIC
Button
POWERCABLE
G‐Sensor
Calibration
button
Black(Ground)
Red(PowerBattery+)
White(PowerACC+)
Green(AlarmIn,NC/NO),(Externalpanicbutton+)
Orange(AlarmIn,Voltage)
Yellow(Alarmout),Low(0V)toHigh(5V)2seconds
Black(Ground),(Externalpanicbutton+)
ExternalPanicButton
(optionalItem)
Cablelength:2m90cm
ButtonCaseSize:18x39x10mm
