Vislink CRIU-ASSY-7005 User Manual

User Manual Focal Point
Camera Control Interface Unit - CRIU-ASSY-7XXX
Issue No: M Page: 15
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
Connector
15-WAY D-Type Socket
Pin
Signal
1
+12V DC
2
RS422 TX+/RS485+
3
RS422 TX- / RS485- / RS232 TX
4
RS422 RX+ / RS232 RX
5
RS422 RX-
6
TTL RXD
7
TTL TXD
8
G TALLY DRY
9
G TALLY WET A
10
G TALLY WET B
11
GND
12
GND
13
R TALLY DRY
14
R TALLY WET A
15
R TALLY WET B
Connector
25-WAY D-Type Socket
Pin
Signal
1
GND
2
Ch. 1. Red Dry
3
GND
4
Ch. 2. Red Dry
5
GND
6
Ch. 3. Red Dry
7
GND
8
Ch. 4. Red Dry
9
GND
10
Ch. 5. Red Dry
11
GND
12
Ch. 6. Red Dry
13
GND
14
Ch. 1. Red Wet A
15
Ch. 1. Red Wet B
16
Ch. 2. Red Wet A
17
Ch. 2. Red Wet B
18
Ch. 3. Red Wet A
19
Ch. 3. Red Wet B
20
Ch. 4. Red Wet A
21
Ch. 4. Red Wet B
22
Ch. 5. Red Wet A
23
Ch. 5. Red Wet B
24
Ch. 6. Red Wet A
25
Ch. 6. Red Wet B
