User Manual Focal Point
Operators Control Panel (OCP5) OCP5-ASSY-7XXX
Issue No: M Page: 44
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
Data output from the OCP5 to the Camera Control Interface Unit may be configured in
either of the following ways:
 OCP I/F connector - this is the normal method which also allows the OCP5 to derive
its power from the Camera Control Interface Unit (see Section 6.2.1)
 Data in/out connector - this method is used where longer lengths of cable are used,
up to the limits for RS485 (see Section 6.2.2)
Use the Data in/out connector to handle the Data input from the camera to the OCP5.
NOTE: When used for return data to the Vislink OCP5, set the User Data port on the
microwave video link (transmitter and the receiver) to a baud rate of 115,200.
OCP5 s Camera Control Function
Control Function
Joystick
Camera Iris
Master Black
Mixer preview
(accessed pressing the control knob)
Control knobs and push buttons
Various
Soft keys for menu selection
Various
Camera Control Functions
*
RGB – White balance
RGB – Black balance
RGB – Flare control
RGB – Gamma control
ND and CC filter control
Master Black Pedestal
Iris control
Auto/manual iris control
Configurable open/close iris limits
Detail
Detail dependency
Saturation
Auto-Knee
Bars
Configurable Panel lockout
Gain steps
White balance presets and fixed temperatures
Table 6-1 OCP5 Control Functions
You can assign a favorite function to the OPT button. Doing this makes it is instantly
available from the OCP5 front panel.
*
Camera model dependent.
