User Manual Focal Point
Camera Control Data Transmitter - FCDT-ASSY-7XXX
Issue No: M Page: 31
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
Figure 4-1 FCDT-ASSY-7XXX Overview
The Camera Control Data Transmitter communicates with the Camera Control Interface
Unit either by fiber optic or wired connections.
The menu options available via the Camera Control Interface Unit set the RF frequency and
RF output power level. The Camera Control Data Transmitter generates the levels.
The unit operates on a +12 to +24V DC input supply.
It can be fix/mounted using a wedge plate on the base of the unit.
WARNING: This unit contains a class 1 laser module. Lasers can cause irriversable eye
damage. Do not stare directly or indirectly at the laser beam.
Figure 4-2 FCDT-ASSY7xxx Connectors and Indicators Overview
