Vislink CRIU-ASSY-7005 User Manual

User Manual Focal Point
Data Receiver
Issue No: M Page: 37
Ref: FOCL-ASUM-8xxx Copyright © 2017 Vislink plc
NOTE: The LDX-80 Camera must have up to date Grass Valley firmware installed (version
22 or greater).
Connector
4-Pin XLR Plug
Pin
Signal
1
GND
2
NC
3
NC
4
+12V
 BNC 75Ω
 BNC 75Ω
 BNC 75Ω
Connector
3-Pin XLR Socket
Pin
Signal
1
GND
2
Hot+
3
Cold-
Connector
5-Pin, 1-Key LEMO Socket
Pin
Signal
1
GND
2
+12V
3
Tally
4
NC
5
NC
Connector
3-Pin Binder Socket
Pin
Signal
1
Data
2
NC
3
GND
