VitaScan LT
User and Service Manual
!
Content of the packaging:
• VitaScan v.2 probe
• USB Memory stick with Application Software and User & Service Manual
• VitaScan v.2 probe holder
• Installation guide in English
Storage
If the system is to be stored, pack it in the original soft case container, and keep it in an
environment free of corrosive material, uctuations in temperature and humidity, and vibration
and shock.
Warning:
Do not have VitaScan LT connected to any device while stored in the original soft case container.
Storage Requirements:
Storage temperature from -30°C to 50°C
Relative humidity of 20% to 90% @ 30°C, non-condensing
Atmospheric pressure from 700 hPa to 1060 hPa
As with most electronic equipment, the unit should be operated in a dry area within normal
temperature limits (+10°C to +45°C, 10% - 80% humidity).
Dispose electronic waste:
VitaScan LT complies with the WEEE Directive (2002/96/EC) marking requirements. The a󰀩xed
label indicates that you must not discard this Medical Electric Equipment in domestic household
waste. Product category: With reference to the equipment types in WEEE directive annex IA,
this product is classed as category 8 “Medical Devices”. To return unwanted products, contact
Vitacon at the address mentioned at the front of this manual or your local VitaScan distributor.
Technical Specicaons - Vitascan v.2
• Volume range: ..............................................................................................0 – 1000 ml
• Accuracy ....................................................... ± 7.5% on volumes greater than 100 ml¹
.........................................................................± 7.5 ml on volumes less than 100 ml¹
• Frequency: ......................................................................................................3.40 MHz
• Acoustic Output: .....................................................MI max: 0.38, Power: 0.25 mW/cm²
• Thermal Index – TI ............................................................................................... < 0.02
• Scanning method: .......................................................................... Sector, 180 degrees
• Rotation positions: ............................................................6, 12 or 24 rotating positions
• Sweep angle: ............................................................................................. 130 degrees
• Max detection depth: ...................................................................... 100, 160 or 230 mm
• Max probe temperature: ......................................... 35°C @ 22°C ambient temperature
• Dimension ...................................... (L x W x H) 18.5 x 4.5 x 4.5 cm (7.3 x 1.8 x 1.8 in.)
• Weight incl. cable: .................................................................................. 0.36kg (0.79lb)
• IP rating: ..................................................................................................................IPX7
• Power Supplied by ........................................................................USB port: 0.5A @ 5V
• Operating conditions: ...........................+10°C to + 45°C, 10 % - 80 % relative humidity
• Storage temperature: ............................................................................. -30°C to +50°C
• PC requirements: ..................................................................................Windows 10 OS
• PC Input method: .................................................... Mouse, keyboard and touchscreen
¹ Accuracy specications in accordance with stated instructions, scanning on Vitacon phantom
and using software version 4.5.4.14 and above.
