Vext/FVC Ratio extrapolated volume of FVC
PIF L/min Peak inspiratory ow (L/min)
Lung Age
Lung age will be displayed if the date of
birth, height, population group and smoking
information have been entered. Lung age will
only be shown if the measured FEV1 value is less
than the lower limit of the predicted normal value
for FEV1.
3.6.5. Subject Options
The following options are available in the Subject Options screen:
• Primary View: Set the default subject list view to either name or ID
using the drop down list.
• Password protection: Select to turn password protection on/off.
Change the password using the touch panel keypad.
• Smoking History, Population Group and Weight: Select whether
to include these elds when creating a new subject on the device.
To change the setting select the on/off button on the touch panel
keypad.
3.6.6. Smart Options
Congure the device to follow a set sequence of operation on power up using
the Smart Options. Turn Smart Options Off/On using the drop down menu.
When turned on there are four areas that may be congured by selecting from a
drop down list:
• After Power Up: Congure the device to go to the Main Menu or the
Subject screen after power up.
• After Subject: Congure the device to go to VC Test, FVC Test or
Main Menu after selecting a subject.
• After VC: Congure the device to go to FVC or Main Menu after
performing a VC test.
• After FVC: Congure the device to go to POST mode, Print the test or
go to the Main Menu after performing an FVC test.
3.6.7. Report Options
Set the Report Content and the Report Method using the Report Options screen.
Report Content
The following information printed on the session reports may be congured by
selecting from a drop down list:
• Table: Congure the device to show the results for the best test only
(Best 1) or the three best tests (Best 3).
• Normal Comparison: Congure the device to print either the % of
