4
2. Tools and their positions
The tools used on the Veloblade Volta and their positions on the machine [see
figure 2.1 below for positions]:
Position 1
• PCTT – Crease tool
Position 2
• RCT – Rotary cutting tool [for materials up to 2mm]
Position 3
• PRCT – Pen tool
• RCT – Rotary cutting tool [in this position we use the RCT for kiss cutting]
Figure 2.1
