Vivitek D755WT SERIES User Manual

DLP Projector—User’s Manual
Top view—On-screen Display (OSD) buttons and LEDs
1
6
2
3
4
5
12
7
8
9
10
11
ITEM LABEL DESCRIPTION
SEE
PAGE:
1.
MENU Opens and exits OSD menus
2.
Navigates in the OSD
Quick Menu – For Keystone
16
3.
SOURCE Enter the Source menu
4.
Navigates and changes settings in the OSD
16
5.
Enter or confirm highlighted OSD menu item
6.
AUTO Optimizes image size, position, and resolution
7.
Navigates and changes settings in the OSD
8.
Navigates in the OSD
Quick Menu – For Keystone
16
9.
Turns the projector On or Off
Red Lamp Fail
10.
LAMP LED
Flashing Error code
Green
Ready to power on (Standby)
Lamp Lit , System stable
Over Temperature
11.
POWER LED
Flashing
System initial, Power on,
Cooling, Error code
12.
TEMP LED Red Over Temperature
52
— 3—
