DLP Projector—User’s Manual
— 64—
APPENDIX I
RS-232C Protocol
RS232 Setting
Baud rate: 9600
Parity
check:
None
Data bit: 8
Stop bit: 1
Flow
Control
None
Control Command Structure
Header code Command code Data code End code
HEX Command Data 0Dh
ASCII ‘V’ Command Data CR
Operation Command
Note:
XX=00-98, projector's ID, XX=99 is for all projectors
Return Result P=Pass / F=Fail
n: 0:Disable/1: Enable/Value(0~9999)
Command Group 00
ASCII HEX Function Description Return Result
VXXS0001 56H 39H 39H 53H 30H 30H 30H 31H 0DH Power On P/F
VXXS0002 56H 39H 39H 53H 30H 30H 30H 32H 0DH Power Off P/F
VXXS0003 56H 39H 39H 53H 30H 30H 30H 33H 0DH Resync P/F
VXXG0004 56H 39H 39H 47H 30H 30H 30H 34H 0DH Get Lamp Hours Pn/F
VXXS0006 56H 39H 39H 53H 30H 30H 30H 36H 0DH System Reset P/F
VXXG0007 56H 39H 39H 47H 30H 30H 30H 37H 0DH Get System Status
0:Reset
1:Standby
2:Operation
3:Cooling
Pn/F
VXXG0008 56H 39H 39H 47H 30H 30H 30H 38H 0DH Get F/W Version Pn/F
Command Group 01
ASCII HEX Function Description Return Value
VXXG0101 56H 39H 39H 47H 30H 31H 30H 31H 0DH Get Brightness n=0~100 Pn/F
VXXS0101n 56H 39H 39H 53H 30H 31H 30H 31H n 0DH Set Brightness n=0~100 P/F
VXXG0102 56H 39H 39H 47H 30H 31H 30H 32H 0DH Get Contrast n=0~100 Pn/F
VXXS0102n 56H 39H 39H 53H 30H 31H 30H 32H n 0DH Set Contrast n=0~100 P/F
VXXG0103 56H 39H 39H 47H 30H 31H 30H 33H 0DH Get Color n=0~100 Pn/F
VXXS0103n 56H 39H 39H 53H 30H 31H 30H 33H n 0DH Set Color n=0~100 P/F
VXXG0104 56H 39H 39H 47H 30H 31H 30H 34H 0DH Get Tint n=0~100 Pn/F
VXXS0104n 56H 39H 39H 53H 30H 31H 30H 34H n 0DH Set Tint n=0~100 P/F
VXXG0105 56H 39H 39H 47H 30H 31H 30H 35H 0DH Get Sharpness 0~31 Pn/F
To Next Page
