PACKAGE CONTENTS
TOOLS NEEDED
WARNING!
Phillips
Screwdriver
A (x1)
Mount
B (x2)
VESA Bracket
C (x4)
Carriage Bolt
M-F (x4)
Washer
M-G (x8)
5mm Spacer
M-H (x8)
15mm Spacer
W-A (x3)
Hex Head
Screw
M-E (x4)
M8x50
M-A (x4)
M5x14
M-B (x4)
M6x14
M-C (x4)
M6x30
M-D (x4)
M8x30
If you do not understand these directions, or if you have any doubts about the safety of the
installation, please call a qualified technician. Check carefully to make sure there are no missing or
defective parts. Improper installation may cause damage or serious injury. Do not use this product
for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity.
We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or
inappropriate use.
NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED
W-C (x3)
Washer
W-B (x3)
Anchor
Drill
D (x4)
Nut
E (x1)
Wrench
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
W-D (x2)
Flat Head
Screw
Studfinder Level Pencil Socket
Wrench
To Next Page
