Vivotek FD8131 - RTSP Multicast, SIP, and RTP Parameters

VIVOTEK
User's Manual - 129
25
7.5.7.1 RTSP multicast
Subgroup of network_rtsp_s<0~(n-1)>: multicast, n is stream count
(capability.protocol.rtp.multicast=1)
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
alwaysmulticast <boolean> 0 4/4 Enable always multicast.
ipaddress <ip address> For n=0,
239.128.1.99
For n=1,
239.128.1.100,
and so on.
4/4 Multicast IP address.
videoport 1025 ~ 65535 5560+n*2 4/4 Multicast video port.
ttl 1 ~ 255 15 4/4 Mutlicast time to live value.
7.5.8 SIP port
Subgroup of network: sip
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
Port 1025 ~ 65535 5060 1/6 SIP port.
(capability.protocol.sip=1)
7.5.9 RTP port
Subgroup of network: rtp
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
videoport 1025 ~ 65535 5556 6/6 Video channel port for RTP.
(capability.protocol.rtp_unicast=1)
